Development Guide¶

Welcome to the Mixtape Society development guide. This section explains how the project is organized, how to set up a local development environment, how to run tests, and where to find the architectural documentation.

📂 Project Structure¶

📁 mixtape‑society/
- 👷‍♀️ .github/
  - ⚙️ workflows/
    - docker-image.yml – Build Docker images on GHCR
    - docs.yml – Publish GitHub Pages
- 🐳 docker/ – Dockerfiles & Compose configs
- 📚 docs/ – MkDocs source (this folder)
- 📂 src/
  - app.py – Flask entry point
  - 📂 audio_cache/ – Audio transcoding & caching
  - auth.py – Authentication utilities
  - 📂 common/ – Infrastructure‑free abstractions
  - 📂 config/ – Environment‑variable handling
  - 📂 logtools/ – Structured logging helpers
  - 📂 mixtape_manager/ – Mixtape persistence layer
  - 📂 musiclib/ – Music indexing (TinyTag + SQLite)
  - 📂 routes/ – Flask blueprints (browser, editor, …)
  - 📂 static/
    - 📂 css/ – Stylesheets for Jinja2 templates
    - 📂 js/ – Front‑end scripts
  - 📂 templates/ – Jinja2 views
  - 📂 utilities/ – Miscellaneous helper functions
- 📄 .gitignore – Ignored files for Git
- 📄 LICENSE – Project license
- 📄 mkdocs.yml – MkDocs site configuration
- 📄 pyproject.toml – Poetry‑style project metadata
- 📄 .python-version – Python version pinning (3.13+)
- 📄 README.md – Repository overview
- 📄 uv.lock – uv‑managed lockfile

Tip

The src/ package is deliberately framework‑agnostic; core modules (musiclib, mixtape_manager, audio_cache) contain no Flask imports, making them easy to unit‑test.

🛠️ Prerequisites¶

Tool	Minimum Version	Install Command
Python	3.13+ (pinned in `.python-version`)	Use your system package manager or `pyenv`
uv (modern Python package manager)	Latest	`curl -LsSf <https://astral.sh/uv/install.sh> \| sh`
Docker (optional, for containerised dev)	Engine ≥ 20.10	Follow Docker’s official install guide

Why uv? It resolves and installs dependencies without a requirements.txt, speeds up virtual‑environment creation, and produces a deterministic uv.lock.

🚀 Local Development Workflow (uv)¶

# 1️⃣ Install runtime dependencies
uv sync

# 2️⃣ Install development‑only dependencies (testing, linting, docs)
uv sync --extra dev

# 3️⃣ Run the Flask development server
uv run python -m app

# 4️⃣ Add a new runtime dependency (updates pyproject.toml & uv.lock)
uv add <package-name>

All commands are executed from the repository root.

The development server automatically reloads when you edit files (Flask’s built‑in reloader is enabled because APP_ENV=development).

🐳 Docker‑Based Development¶

The repository ships with a Docker Compose configuration for rapid iteration:

# Build the development image
docker compose -f docker/docker-compose.yml build

# Start the stack (Flask + optional reverse‑proxy)
docker compose -f docker/docker-compose.yml up -d

The compose file mounts the source code into the container, so you can edit files locally and see changes instantly (no hot‑reload inside the container, but the Flask dev server picks up changes).

Useful shortcuts¶

Command	What it does
`docker compose logs -f mixtape`	Tail the Flask logs.
`docker compose exec mixtape bash`	Drop into the container shell.
`docker compose down -v`	Tear down and delete the persisted volume (useful for a clean start).

🏛️ Architectural Documentation¶

This section dives into the inner workings of Mixtape Society. Each page focuses on a specific subsystem, explains its responsibilities, and shows how it interacts with the rest of the project.

Core Modules¶

Module	What it does
Music Library (`musiclib`)	Handles scanning, indexing, and full‑text search of the audio collection (TinyTag + SQLite FTS5).
Mixtape Manager	Persists mixtape JSON files, manages cover images, and provides CRUD operations.
Audio Caching	Transcodes FLAC files to MP3/OGG on‑demand, stores them in a cache, and streams via HTTP range requests.
Progressive Web App (PWA)	Enables offline playback for public shared mixtapes via service workers, smart caching, and installable app features.
Configuration	Centralised environment‑variable handling, directory layout, and defaults.
Utilities	Helper functions (logging, image processing, misc tools).

Flask Application (Entry Point)¶

The app.py file wires everything together:

Initializes the Flask app, CORS, and rate limiting.
Sets up core services (MusicCollectionUI, MixtapeManager, AudioCache).
Registers blueprints for auth, browser, play, editor, and OG‑cover routes.
Provides global error handling (e.g., DatabaseCorruptionError).

📄 Read the full walkthrough

Blueprint / Route Overview¶

Blueprint	URL Prefix	Primary Concern
Authentication	`/auth`	Login / logout, session handling.
Browser	`/mixtapes`	List, play, delete, and serve static mixtape files.
Play	`/play`	Audio streaming endpoint (`/play/<slug>`), range requests, and public player page.
Editor	`/editor`	Mixtape creation / editing UI, JSON save, cover generation, and background caching trigger.
OG‑Cover	`/og`	Dynamic Open‑Graph images for social sharing.

Each blueprint has its own Markdown file that details the routes, request flow, and any special middleware:

🔀 Data Flow Summary¶

flowchart TD
    subgraph Client
        UI["Web UI"]
    end

    subgraph Server
        A["Flask app (app.py)"]
        B[MusicCollectionUI]
        C[MixtapeManager]
        D[AudioCache]
        E[Routes]
    end

    UI -->|HTTP request| A
    A -->|calls| B
    A -->|calls| C
    A -->|calls| D
    A -->|dispatches to| E

    B -->|reads/writes| SQLite[(SQLite DB)]
    C -->|reads/writes| JSON[(Mixtape JSON files)]
    D -->|stores| Cache[(Cached audio files)]

    style Client stroke:#333,stroke-width:1px
    style Server stroke:#333,stroke-width:1px

Hold "Alt" / "Option" to enable pan & zoom

The diagram illustrates how a request travels from the browser through the Flask entry point, into the core services, and finally reaches the persistent storage.

🛡️ Contributing Guidelines¶

Fork the repository and create a feature branch (git checkout -b feature/awesome-feature).
Install dev dependencies (uv sync --extra dev).
Lint & format (uv run ruff check . && uv run ruff format .).
Commit with a clear, conventional‑commit‑style message.
Open a Pull Request targeting master. Include:
- A concise description of the change.
- Screenshots or diagrams if UI is affected.
- A reference to any related issue (Closes #123).

Tip

Code Style – Follow the existing codebase: type hints everywhere, use logtools.get_logger for logging, and keep Flask‑specific code inside the routes/ package.

🧭 Where to Go Next?¶

Deep dive into a module – Click any link in the tables above.
Explore the code – All source files live under src/ (e.g., src/musiclib/reader.py).
Contribute – Follow the guidelines in this page and submit a PR.

Happy hacking! 🎧🚀
